Delphi DCM 7.24 JCB to OBD Bench Cable

Only 2 left
SKU: 22124472200425
£100.00

Ready to work out of the box!

All tools are delivered with essential accessories and easy-to-follow instructions. Unbox and start your projects with confidence!

Got questions?

Feel free to get in touch

Ask an expert!

Video chat Chat Email +447349270696

Delphi DCM 7.24 to OBD Bench Cable – JCB

Engineered for professional bench programming, diagnostics, and ECU testing on JCB vehicles equipped with Delphi DCM 7.24 engine control units.

Specifications

  • ECU Side: Custom-pinned for Delphi DCM 7.24
  • Diagnostic Side: Standard OBD-II male connector
  • Power Input: 2.1mm x 5.5mm barrel-type DC jack (external power supply required)
  • Switched Power: Integrated power switch for safe, controlled ECU power cycling
  • CAN Bus: Toggle switch for 120Ω CAN termination resistor, ensuring stable communication during bench operations
  • Cable Construction: Automotive-grade, shielded for EMI protection and durability
  • Length: 1.2m standard (custom options available)
  • Identification: Clearly labelled pinout and function markings for error-free use

Technical Details

  • Direct ECU-to-OBD Connection: Enables seamless communication between Delphi DCM 7.24 ECUs and standard OBD-II diagnostic tools or programming interfaces.
  • Power Management: External DC power input with switched output allows for safe handling and prevents accidental power cycles during programming or diagnostics.
  • CAN Bus Termination: Toggleable 120Ω resistor provides proper CAN bus termination, critical for reliable bench communication and accurate diagnostics.

Supported Vehicles

  • JCB (with Delphi DCM 7.24 ECU)

Key Benefits

  • Purpose-built for Bench Work: Simplifies ECU programming, cloning, and diagnostics without requiring the vehicle harness.
  • Safe and Reliable: Power and CAN termination switches protect both the ECU and diagnostic equipment.
  • Professional Quality: Manufactured and tested to CreativeOBD’s high standards for repeatable, reliable results.

Typical Use Cases

  • ECU bench programming (read/write/clone)
  • Diagnostics and troubleshooting
  • Tuning and calibration
  • ECU repair and recovery
